Stainless steel wire mesh for gas-liquid separator

Short Description:

Material: SS304, SS304L, SS316, SS316L

Yutai is experienced in producing woven wire mesh and wire. Stainless steel wire mesh also named stainless steel wire cloth. Here we introduce stainless steel woven wire mesh and stainless steel woven wire cloth products.

Varieties according to materials:
304 Stainless steel wire mesh;
304L Stainless steel wire mesh;
316 Stainless steel wire mesh;
316L Stainless steel wire mesh

Send email to us

Product Detail

Product Tags

Basic Information

Stainless steel wire mesh, with its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.

Weaving Patterns: Plain weave, twill weave, Dutch weave.

Stainless steel wire clothes is weaved with high quality stainless steel wires and is special for filtering and screen printing.

Features

High tension, much higher tension than common polyester mesh and property is very stable;
Super Precision: Uniform wire diameter and aperture with extremely low difference;
Low Elongation: very small elongation of wire mesh at high tension;
High Flexibility: the wire mesh will not lose elasticity at extreme tension
High Corrosion Resistance: the excellent corrosion resistance of stainless steel wire exceeds polyester fiber
Non-electrostatic: to avoid effects of non-electrostatic for print and ensure the safety of printing
Good Heat-melting Resistance: to avoid the effects of any solvents to wire mesh and to ensure the safety of printing

Application

Stainless steel wire cloth is widely used in the plate making of electronics, textiles, ceramics, glass and other industries and filtration of aviation of aviation air space and petrochemical industries.

Advantages

Super Precision: Uniform wire diameter and aperture with extremely low difference;
Low Elongation: Very small elongation of wire mesh at high tension;
High Flexibility: The wire mesh will not lose elasticity at extreme tension;
High Corrosion Resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber;
Non-electrostatic: To avoid affects of non-electrostatic for print and ensure the safety of printing;
Good Heat-melting Resistance: Special features of steel wire mesh. Suitable for heat-melting ink;
Good Solvent Resistance: To avoid the effects of any solvents to wire mesh and to ensure the safety of printing;

Specifications

Mesh/Inch	Wire Diameter		Aperture		Open Area	Weight(LB) /100 Square Foot
Mesh/Inch	Inch	MM	Inch	MM	Open Area	Weight(LB) /100 Square Foot
1x1	0.080	2.03	0.920	23.37	84.6	41.1
2X2	0.063	1.60	0.437	11.10	76.4	51.2
3X3	0.054	1.37	0.279	7.09	70.1	56.7
4X4	0.063	1.60	0.187	4.75	56.0	104.8
4X4	0.047	1.19	0.203	5.16	65.9	57.6
5X5	0.041	1.04	0.159	4.04	63.2	54.9
6X6	0.035	0.89	0.132	3.35	62.7	48.1
8X8	0.028	0.71	0.097	2.46	60.2	41.1
10X10	0.025	0.64	0.075	1.91	56.3	41.2
10X10	0.020	0.51	0.080	2.03	64.0	26.1
12X12	0.023	0.584	0.060	1.52	51.8	42.2
12X12	0.020	0.508	0.063	1.60	57.2	31.6
14X14	0.023	0.584	0.048	1.22	45.2	49.8
14X14	0.020	0.508	0.051	1.30	51.0	37.2
16X16	0.018	0.457	0.0445	1.13	50.7	34.5
18X18	0.017	0.432	0.0386	0.98	48.3	34.8
20X20	0.020	0.508	0.0300	0.76	36.0	55.2
20X20	0.016	0.406	0.0340	0.86	46.2	34.4
24X24	0.014	0.356	0.0277	0.70	44.2	31.8
30X30	0.013	0.330	0.0203	0.52	37.1	34.8
30X30	0.012	0.305	0.0213	0.54	40.8	29.4
30X30	0.009	0.229	0.0243	0.62	53.1	16.1
35X35	0.011	0.279	0.0176	0.45	37.9	29.0
40X40	0.010	0.254	0.0150	0.38	36.0	27.6
50X50	0.009	0.229	0.0110	0.28	30.3	28.4
50X50	0.008	0.203	0.0120	0.31	36.0	22.1
60X60	0.0075	0.191	0.0092	0.23	30.5	23.7
60X60	0.007	0.178	0.0097	0.25	33.9	20.4
70X70	0.0065	0.165	0.0078	0.20	29.8	20.8
80X80	0.0065	0.165	0.0060	0.15	23.0	23.2
80X80	0.0055	0.140	0.0070	0.18	31.4	16.9
90X90	0.005	0.127	0.0061	0.16	30.1	15.8
100X100	0.0045	0.114	0.0055	0.14	30.3	14.2
100X100	0.004	0.102	0.0060	0.15	36.0	11.0
100X100	0.0035	0.089	0.0065	0.17	42.3	8.3
110X110	0.0040	0.1016	0.0051	0.1295	30.7	12.4
120X120	0.0037	0.0940	0.0064	0.1168	30.7	11.6
150X150	0.0026	0.0660	0.0041	0.1041	37.4	7.1
160X160	0.0025	0.0635	0.0038	0.0965	36.4	5.94
180X180	0.0023	0.0584	0.0033	0.0838	34.7	6.7
200X200	0.0021	0.0533	0.0029	0.0737	33.6	6.2
250X250	0.0016	0.0406	0.0024	0.0610	36.0	4.4
270X270	0.0016	0.0406	0.0021	0.0533	32.2	4.7
300X300	0.0051	0.0381	0.0018	0.0457	29.7	3.04
325X325	0.0014	0.0356	0.0017	0.0432	30.0	4.40
400X400	0.0010	0.0254	0.0015	0.370	36.0	3.3
500X500	0.0010	0.0254	0.0010	0.0254	25.0	3.8
635X635	0.0008	0.0203	0.0008	0.0203	25.0	2.63
